23-Pieces FWD Wheel Bearing Press Kitfor Front Wheel Drive
Bearing Removal & Installation with Sliding Screws
|
Product Name
|
FRONT WHEEL DRIVE BEARING TOOL SET
|
|
|
Model Number
|
SL-XC4040
|
|
|
Kit-Quantity
|
23-Furnaces
|
|
|
Material
|
Carbon Steel
|
|
|
Extra Durable
|
Heavy-duty carbon steel construction with black anodic oxidation coating for ultimate rust-resistant performance. The wheel drive bearing puller set is packed in a heavy-duty, blow-molded case with precision-sized compartments for every piece - great for storage and transport.
|
|
|
Specification
|
Long 7.5"x Diameter 0.75"/16
|
|
|
Sleeve Plates
|
3.25" O.D. x 2.72" Step, 4" O.D. x 3.2" Step
|
|
|
Sleeve
|
3"OD x Long 2.5"; 3.25"OD x Long 2.53"; 3.63"OD x Long 2.53"; 4"OD x Long 2.53"
|
|
|
Bushings
|
2.19", 2.50", 2.63",2.78", 2.83", 2.83", 2.87", 2.90", 2.94", 3.05", 3.20", 3.29", 3.47" O.D.
|
|
|
Sliding Screw
|
7.5" Long x 0.75"
|
|
|
Dia hex nut
|
3" Long x 0.75" Dia
|
|
|
Washers
|
1.52"(38.6mm) O.D. 0.91"(23mm) I.D.
|
|
|
Wide Application
|
The bearing removal tool works with front-wheel drive hub bearing assembly parts on most front-wheel-drive American domestic and imported cars and small pickup trucks.
|
|
|
Package Includes
|
13 pcs Adapter Drift size-50mm, 55mm, 60mm, 64mm,67mm, 70mm, 72mm, 74mm, 75mm, 78mm, 82mm, 84mm, 88mm;
4 pcs Receiver Sleeves sizes - 102mm, 91mm, 86.3mm, 76mm;
2 pcs Drive Shaft sizes- 32mm and 38mm
|
|
|
Package Weight
|
10.80 KG
|
|
|
Package
|
Blow Mould Case
|
|
|
Package Size
|
420*360*100mm
|
|
|
OEM & ODM
|
Acceptable
|
|
Details Images
23-Pieces FWD Wheel Bearing Press Kit The front wheel drive bearing tool kit comes with all the tools you need to make removal and installation a breeze. The wheel drive bearing puller set works with front-wheel drive hub bearing assembly parts on most front-wheel-drive American domestic and imported cars and small pickup trucks. Premium QualityThe front wheel drive bearing tool kit comes with all the tools you need to make removal and installation a breeze.Laser Etched SizeThe wheel drive puller set including multiple sizes of drifts, and the kit can be used for different models.Heavy-duty Sliding ScrewHeavy-duty carbon steel construction with black anodic oxidation coating for ultimate rust-resistant performance.Easy StorageThe front wheel drive bearing tool kit comes with all the tools you need to make removal and installation a breeze.
How to Replace:Step.1 Determine if the vehicle has a trapped rotor or a floating rotor.
Step.2 Assemble the tool components, and press out the worn bearing.
Step.3 Lightly lubricate the new bearing, and position it for installation with the tool components assembled. Press the bearing into the spindle assembly until it bottoms.
Step.4 Fasten the bearing retainer in place using the bearing retainer bolts. (On Neon vehicles, install the snap ring in the knuckle.)
Step.5 Assemble tool components. Lightly oil the hub assembly, and install the hub. Attention: The bearing installer must be assembled with the flat side toward the bearing and the small diameter pilot on the side away from the bearing.
Step.6 Assemble the remaining vehicle components that were removed for bearing replacement: (1)lower ball joint to steering knuckle assembly brake rotor. (2)disc brake caliper. (3)outer tie rod nut and tie rod. (4)axle nut. (5)front tires.
