Description
Benefits and Features
-
Traction block tread design for high drive wheel efficiency in all seasons
-
Aggressive blading helps provide road-gripping traction
-
Open shoulder produces powerful traction on wet and dry roads
CM986
| Size | LR/PR | Service index |
Tread Depth (mm) |
Standard Rim |
Overall Diameter (mm) |
Section Width (mm) |
Max. Load Capacity at Cold Inflation Pressure | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Single | Dual | |||||||||||||
| (kg) | (lbs) | (kPa) | (psi) | (kg) | (lbs) | (kPa) | (psi) | |||||||
| 245/70R17.5 | H/16 | 136/134M | 15.0 | 7.50 | 789 | 248 | 2240 | 4940 | 850 | 123 | 2120 | 4675 | 850 | 123 |
| 245/70R17.5 | J/18 | 143/141J | 15.0 | 7.50 | 789 | 248 | 2725 | 6005 | 875 | 128 | 2575 | 5675 | 875 | 128 |
| 205/75R17.5 | G/14 | 124/122M | 14.0 | 6.00 | 753 | 205 | 1600 | 3525 | 750 | 109 | 1500 | 3305 | 750 | 109 |
| 215/75R17.5 | H/16 | 135/133J | 14.5 | 6.00 | 767 | 211 | 2180 | 4805 | 850 | 123 | 2060 | 4540 | 850 | 123 |
| 225/75R17.5 | G/14 | 129/127M | 14.5 | 6.75 | 783 | 226 | 1850 | 4080 | 725 | 105 | 1750 | 3860 | 725 | 105 |
| 235/75R17.5 | G/14 | 132/130M | 15.4 | 6.75 | 797 | 233 | 2000 | 4410 | 775 | 112 | 1900 | 4190 | 775 | 112 |
| 235/75R17.5 | H/16 | 143/141J | 15.4 | 6.75 | 797 | 233 | 2725 | 6005 | 875 | 128 | 2575 | 5675 | 875 | 128 |
| 225/70R19.5 | F/12 | 125/123M | 15.0 | 6.75 | 811 | 226 | 1650 | 3640 | 660 | 95 | 1550 | 3415 | 660 | 95 |
| 245/70R19.5 | G/14 | 133/131M | 15.4 | 7.50 | 839 | 248 | 2060 | 4540 | 760 | 110 | 1950 | 4300 | 760 | 110 |
| 245/70R19.5 | H/16 | 136/134M | 15.4 | 7.50 | 839 | 248 | 2240 | 4940 | 830 | 120 | 2120 | 4675 | 830 | 120 |
| 285/70R19.5 | H/16 | 146/144K | 16.0 | 8.25 | 895 | 283 | 3000 | 6610 | 850 | 123 | 2800 | 6175 | 850 | 123 |
